The fischer insulation fixing FID-R is a fixing for mounting rainwater downpipes without thermal bridges in external thermal insulation composite system (ETICS) with a thickness of 100 mm. When installed with a cordless screwdriver, the spiral thread taps itself in the insulation board. The included white covering rosette protects again humidity.

Πλεονεκτήματα - Οφέλη

• Since the anchor is set exclusively in the insulation itself, fixtures can be installed without thermal bridges. The anchor offers an energy-optimised fixing.
• The hard-centering tip cuts its own way through the plaster, without the need for pre-drilling, thus saving a stage of installation.
• The TX-drive allows for setting with standard tools, thus allowing for a fast and economic installation.

[tab name="Τοποθέτηση"]

Λειτουργία

• The installation is carried out without any special tools.
• The spiral thread taps itself in the insulation board.
• For the installation in wood fibre insulating boards a pre-drilling of the insulating board with 16 mm is necessary.
• For the installation before plastering the threaded rod is protected by a tube sleeve.
• The included white covering rosette with glued on PE sealing disc protects again humidity.

1. Τοποθέτηση βύσματος για στήριξη υδρορροών σε μόνωση με επίχρισμα

2. Τοποθέτηση βύσματος για στήριξη υδρορροών σε μόνωση χωρίς επίχρισμα

[tab name="Χαρακτηριστικά"]

Τεχνικά Χαρακτηριστικά
